Braille lettering - digital
Digital Braille print - on sheets or roll-roll
![Digital Braille - printer roll-roll](https://2354d0eb1a.clvaw-cdnwnd.com/dad1dd7f50377e58a8fa7f9e063b1a51/200000013-1bc7f1bc82/SMAG%20VEGA%20Digital%20Braille-3.jpg?ph=2354d0eb1a)
Digital Braille - printer roll-roll
Digital printing of UV varnish using print heads with variable amount of varnish for each Braille point with on-line UV drying
The Braille Printhead can print up to 2 Braille lines, one unit can contain 1 to 4 printheads. The unit includes software for entering print data and a system of supply and distribution of UV varnish to each printhead.
The Braille Printhead can print up to 2 Braille lines, one unit can contain 1 to 4 printheads. The unit includes software for entering print data and a system of supply and distribution of UV varnish to each printhead.
- Braille points from 0.2 to 0.4 mm height
- Print speed up to 50 m / min
- Printed materials paper, self-adhesive materials, PP, PE, PVC, PET and PA plastics
- Operating temperature 35 ° C to 50 ° C depending on UV varnish
- Compressed air requirement 8 bar without water and oil droplets
- Permissible ambient temperature + 18 ° C to + 30 ° C
- Permissible relative air humidity 0 to 90% at 30 ° C non-condensing
- Sample Braille tolerance at 50 m / min 20 characters +/- 0.5 mm
Digital Braille - tolerance
![](https://2354d0eb1a.clvaw-cdnwnd.com/dad1dd7f50377e58a8fa7f9e063b1a51/200000014-c48b1c48b3/Digital%20Braille%20-%20tolerance-5.jpg?ph=2354d0eb1a)
Digital Braille on sheets - diagram
![](https://2354d0eb1a.clvaw-cdnwnd.com/dad1dd7f50377e58a8fa7f9e063b1a51/200000015-541b5541b7/Digital%20Braille%20-%20archy%20schema-3.jpg?ph=2354d0eb1a)
![Digital Braille Printhead](https://2354d0eb1a.clvaw-cdnwnd.com/dad1dd7f50377e58a8fa7f9e063b1a51/200000016-2831a2831c/Braille%20hlava-4.jpg?ph=2354d0eb1a)
Digital Braille Printhead
